1HZ/1HD-FT Servicing

In order to maintain optimum performance and longevity of your loyal Toyota it’s important to ensure the correct maintenance and servicing is upheld. As these engines age it becomes more critical than ever to love them juuuust the right way.



The maintenance schedule we’ve outlined below is what is recommended by Toyota themselves. This information can be found in the factory Toyota ‘Warranty and Service’ manual, however chances are this little book of history has long departed your humble glove box.



NOTE: If you're viewing this on a mobile device you will need to scroll across to see the whole table.

PART/FLUID

ACTION

KM

MONTHS

ENGINE OIL

REPLACE

5000

3

GREASE NIPPLES

LUBRICATE

5000

3

ENGINE OIL FILTER

REPLACE

10 000

6

PRE-FUEL FILTER (HZJ75)

REPLACE

10 000

6

BRAKE/CLUTCH FLUID

TOP UP IF REQ'D

10 000

6

VALVES (1HD-FT)

ADJUST

20 000

12

MAIN FUEL FILTER

REPLACE

20 000

12

WHEEL BEARING GREASE

REPLACE

20 000

12

DIFF OILS

REPLACE

30 000

18

GEARBOX OIL

REPLACE

30 000

18

TRANSFER OIL

REPLACE

30 000

18

VALVES (1HZ)

ADJUST

40 000

24

DRIVE BELTS

REPLACE

40 000

24

COOLANT

REPLACE

40 000

24

BRAKE FLUID

REPLACE

40 000

24

AIR FILTER

REPLACE

100 000

60

TIMING BELT

REPLACE

100 000

60

ALL components should be inspected for serviceability at the 5000km interval.


Other consumable components will require replacing depending on their unique serviceability, such as brake pads and rotors. Please keep in mind this is Toyota's recommendations only and individual opinions may vary, for example we choose to replace our oil filter every 5000km with the engine oil.



Recording your servicing and maintenance is just about as important as doing the work itself. It gives you a reliable reference for previous work completed in case you need to look back, and if you’re keeping everything up to date it’s a great selling point for ensuring a decent resale if you ever decide to part ways with your noble steed.



As we mentioned earlier, your factory manual may be long lost or like us, full of information with no more room to spare. Due to this, we have created our own log to keep our records safe.



This is easy to do if you're mildly proficient in Microsoft Word, just knock up some blank tables and label the columns across the top such as the example below:

KM

DATE

DETAILS

MECHANIC

530 000

18/03/23

ENGINE OIL/FILTER - PENRITE 15W40

SELF-SERVICE

If you’re not up on the technology bandwagon and your son/daughter has pissed off to Europe for the summer don't fret, we've added a 20 page downloadable PDF below which you can grab for free and print at home.

VEHICLE MAINTENANCE AND SERVICING RECORD
.pdf
Download PDF • 380KB


Below you will find Ryco filter part numbers for both 1HZ and 1HD-FT engines:

FILTER TYPE

RYCO PART NUMBER

OIL FILTER

Z334

AIR FILTER

A340

PRE-FUEL FILTER (1HZ ONLY)

R2590P

MAIN FUEL FILTER

Z252X

The following table shows service fluid volumes for both 1HZ and 1HD-FT engines:

SERVICE FLUID

1HZ

1HD-FT

ENGINE OIL

9.3L

11.5L

DIFFS

2.5L EA

2.6L EA

TRANSFER CASE

2.2L

1.5L

GEARBOX

4.9L

2.7L

COOLANT

10.6L

13.2L

Treat your baby well, and hopefully she will return the favour for years to come.
